Outdoor 8 Camera Wireless Cctv Systems , House Security Camera Kit 1080P

Product Categories
Shenzhen Winbo Digital Co., Ltd.
Contact Now

Outdoor 8 Camera Wireless Cctv Systems , House Security Camera Kit 1080P

  • 1
  • 2

Brand Name : WINBO

Model Number : SAV-W15LN08K20

Certification : CE-RED, ROHS,GS

Place of Origin : China

MOQ : 1set

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 3000 sets a month

Delivery Time : within 3-7 working days upon receipt of payment(sample order)

Packaging Details : Neutral factory box

Compression : H.265

Camera Resolution : 1080P

Network : RJ45 / WIFI 802.11b/g/n

Hardisk : Max 4TB

USB Interface : 2 * USB 2.0

Day&Night : Auto

LCD Screen : 1920*1080

Waterproof : IP66

Contact Now

Outdoor WiFi CCTV Camera Kit Built in 15.6 Inch 1080P 8Channel Wireless NVR

Quick Detail

WIFI NVR Kit SAV-W15LN08K20 is adopting the automatic password generation mechanism to ensure that the monitored video will not be eavesdropped if the default password is used. It is very simple to operate and suitable for all kinds of scenes. The Wifi Kits are loved by a majority of users.

Features

  • High Resolution LCD Screen Resolution up to 1920X1080.
  • True 8 X 1080P HD IP cameras are exceptionally smooth, night vision is up to 100ft in the dark with IR-CUT double filter lens.
  • Wireless 8 channels NVR plug and play system. Easy to set up and DIY Installation. only need to plug them in power to start working with AUTO-PAIR technology.
  • Remote Viewing Anywhere Anytime. You can view the cameras remotely on your smartphone, iPad or PC anywhere anytime once the system is set up.
  • Motion Alerts: Push Notifications Instantly When Motion are Detected.

Specifications

Model SAV-W15LN08K20
Wireless NVR Specification
Operating System Embedded Linux OS
LCD Screen 15.6 inch 1920 * 1080 LCD Screen
Network Video 8CH
Network video input broadbank 20 Mbps
AUdio Bitrate 64 Kbps
HDMI input 1 ch,resolution:1024x768,1366x768,
1440x900,1920x1080p
VGA output 1ch,resolution:1024x768,1366x768,
1440x900,1920x1080p
Video Resolution D1/720P/960P/1080P
synch-playback 8CH
Video/Capture mode Maual, Time, Motion, Alarm
Playback mode Real time, Routine, Event
Backup USB backup
Alarm Input 4CH (optional)
Alarm Output 1ch (optional)
Type 1*SATA interface
Max Capacity 4 TB at most for each
Network Interface 1 adaptable RJ45 10M/100M, 1 WIFI interface
USB Interface 2 USB 2.0
Protocol UPnP (play&plug)/SMTP (email survice) / PPPoE (dial-up)
DHCP (Automatically obtain an IP address), etc…
Power Supply DC12V3A
Power Consumption (W) ≤5W(Without HDD)
Operate Temperature (°C) -10℃~+55℃
Working Humidity (%) RH 10%~90%
Size 257mm(W)×210mm(V)×45mm(H)
Weight(excluding HDD) ≤1Kg
IP Camera Specification
Sensor 1/3" Progressive Scan Sensor
Signal System PAL/NTSC
Resolution 1080P 16 : 9 High Defination
Minimum illumination Color: 0.1 Lux; B/W: 0.01 Lux
Shutter 1/25s to 1/25,000s
Lens 3.6mm
OSD Date Time & Title
White Balance Auto
Day&Night Auto / Color / BW
3D-DNR Auto
Mirror/Flip On / Off
Frame Specification Three Streaming at the Same Time:
H.264 128x720@30fps or below
H.264 640x480@30fps or below
S/N > 39.1 Db
Interface RJ45 / WIFI 802.11b/g/n
Anti-thunder Level Standard IEC61000-4-5
Working Temperature -20℃ to +60℃ / 20% to 90% RH
Power Input DC12V-1A
Power consumption ≤6W
Size 205(L)×70(W)×55 (H)mm
Weight 500g
Waterproof IP66

Packing List

1 PCS * 8CH WIFI 15inch LCD NVR
8 PCS * WIFI IP camera
8 PCS * Adaptor for 4pcs IP camera
1 PCS * Adaptor for WIFI NVR
1 PCS * USB Mouse
1 PCS * User Manual

Application
SAV-W15LN08K20 suitable for a wide range of video surveillance applications, including government and industrial buildings, retail environments, hotel, home and schools.
